Technical Parameters General Model: Fisher Baumann 24000C Control Valve Type: Pneumatic Actuated, Cage-Guided Globe Valve Body Primary Application: High-pressure drop, anti-cavitation, and noise attenuation services. Valve Body Size Range: 1/2 inch to 4 inches (DN 15 to DN 100) Pressure Class: ANSI 150, 300, 600, 900, 1500, 2500 (depending on size and construction) End Connections: Flanged (RF, RTJ), buttweld, socket weld, or threaded. Body Materials: Carbon Steel (WCC), Stainless Steel (CF8M/316), Alloy 20, Duplex Stainless Steel, and other alloys. Actuator Type: Spring-and-Diaphragm Pneumatic Actuator. Action: Fail-Close (Air-to-Open) or Fail-Open (Air-to-Close) configurations available. Spring Ranges: Multiple standard spring ranges are available (e.g., 0.2-1.0 bar, 0.4-2.0 bar, etc.) to match available air supply and required thrust. Trim & Performance Trim Type: Baumann "C" Multi-Stage, Anti-Cavitation Trim. The flow path is split into multiple stages, each dissipating a portion of the pressure energy to prevent cavitation. Flow Characteristic: Modified linear or equal percentage, inherent to the multi-stage cage design. Leakage Class: ANSI Class IV (standard metal seat). ANSI Class V or VI (soft seat) is available for applications requiring tight shutoff. Noise & Cavitation Control: Significantly reduces noise (typically by 10-20 dBA) and eliminates cavitation damage compared to standard single-orifice valves. Flow Capacity Cv Range: Available in a wide range of Cv values, selected by choosing the appropriate trim size and number of stages for the specific application. Exact Cv values are determined by the trim designation (e.g., C-1, C-2, etc.). Pressure & Temperature Max Inlet Pressure: Up to ANSI Class 2500 rating (e.g., ~420 bar @ 100°F / 38°C for Class 2500). Temperature Range: Standard packing from -29°C to 232°C (-20°F to 450°F). High-temperature designs are available for services up to 538°C (1000°F). Options & Accessories Positioner: Fisher FIELDVUE DVC6200 or other pneumatic/high-performance positioners can be mounted. Limit Switches: Solenoid valves, proximity switches, and other accessories. Air Sets: Filter regulators (Type 67SR) can be mounted directly on the actuator. Packing: Standard V-ring, low-emission live-loading, or bellows seal options.

Technical Parameters Parameter Specification / Options Series Fisher Baumann 26000 Type Low-Flow Globe Control Valve Flow Characteristic Linear, Equal Percentage, Quick Opening (depends on trim) End Connections 1/4 in., 3/8 in., 1/2 in. NPT (Common); 6 mm, 10 mm Tube; Swagelok® Body Materials Brass (Standard), 316 Stainless Steel, Alloy C-276, Monel Trim Materials 316 Stainless Steel, 17-4PH Stainless Steel, Alloy C-276 Pressure Rating Varies with body material and size. - Brass: Up to 600 psig (41 bar) - Stainless Steel: Up to 2500 psig (172 bar) or higher. Temperature Range -40°F to 500°F (-40°C to 260°C); higher with special packing. Flow Capacity (Cv) From 0.00002 to 0.1 (Extremely low flow range) Leakage Class ANSI Class II, IV, V, VI (depends on trim design)

Technical Parameters Parameter Specification / Options Series Fisher Baumann 51000 Type High-Performance, Cage-Guided Globe Valve Trim Type Balanced, Cage-Guided Flow Characteristic Linear, Equal Percentage, Modified Parabolic Body Styles Globe, Angle End Connections Flanged (ANSI Class 150 to 2500), Butt-Weld, Socket Weld Body Materials Carbon Steel (WCB), Stainless Steel (CF8/CF8M), Alloy Steel (WC6/WC9) Trim Materials Stainless Steel, Hardened Stainless Steel, Stellite Pressure Rating ANSI Class 150 to 2500 (Up to 4500 psig / 310 bar) Temperature Range -450°F to 1200°F (-268°C to 649°C) with special designs and materials. Flow Capacity (Cv) Varies by size and trim, covering a wide range from low to very high flow. Noise Reduction Capable of 15-20 dBA or more of noise attenuation. Leakage Class ANSI Class IV (Standard), ANSI Class V & VI available.

Technical Parameters Parameter Specification Model Fisher Digital Isolation DSV1000 Type Digital Signal Isolator / Converter Isolation 1500 V AC (Input to Output to Power) Input Signals 4-20 mA HART, Voltage, Discrete Output Signals 4-20 mA, Foundation Fieldbus, Profibus PA Power Supply 18-30 V DC (for analog operation); Power via Fieldbus segment for digital output. HART Communication Supports HART 5/6/7 protocol on the analog input side. Fieldbus Communication Supports Foundation Fieldbus H1 or Profibus PA Accuracy ±0.05% of span (for analog inputs) Ambient Temperature Limits -4°F to 185°F (-20°C to 85°C) Mounting Standard 35 mm DIN Rail Enclosure Module for mounting inside a control panel cabinet.

Technical Parameters Parameter Specification Product Name Fisher Whisper™ NXG Trim Type Multi-Stage, Noise Attenuation & Anti-Cavitation Trim Primary Function Noise Reduction & Cavitation Control Noise Reduction Capability Up to 25 dBA or more, depending on application conditions. Pressure Drop Capability Capable of handling very high pressure drops (ΔP), often in excess of 1000 psi. Compatible Valve Bodies Fisher easy-e™ ES, G-Series, 1050/1051, and other cage-style globe valves. Trim Construction Stacked disks/plates with precision-engineered micro-perforations and flow channels. Wetted Materials Stainless Steel (Standard), Alloy Steel, Stellite-hardened for erosive services. Size Range Designed to fit valve sizes from 1" to 12" (DN 25 to DN 300) and larger. Temperature Limits Limited by the valve body and gasketing, typically up to 800°F (427°C) or more. Flow Capacity (Cv) Varies by size and specific NXG trim design. Provides a balanced Cv for its noise reduction class.

Technical Parameters Parameter Specification Model Fisher 644 (Reducing) Fisher 645 (Backpressure/Relief) Type Pilot-Operated Pressure Controller Function Pressure Reducing Backpressure Relief Body Materials Ductile Iron (Standard), Cast Iron, Carbon Steel End Connections Flanged (ANSI Class 150, 300, 600); Butt-Weld Size Range (Main Valve) 1" to 8" (DN 25 to DN 200) Maximum Inlet Pressure (P1) Up to 1440 psig (99 bar) for ANSI 600 models. Outlet Pressure Range (P2) Wide range available via interchangeable pilot springs. Temperature Range -20°F to 150°F (-29°C to 66°C) with standard elastomers. Flow Capacity (Cv) Very high. Example (2" 644): Cv ~ 45

Technical Parameters Parameter Specification Product Name Fisher HVP (High Velocity Pitot) Valve Type Specialized Shut-Off Valve for Pitot Tubes Function Isolation for In-line Removal/Insertion of HVP Flow Elements Body Materials Carbon Steel (WCB), Stainless Steel (CF8) End Connections Flanged (ANSI Class 150 to 600), Butt-Weld Pressure Rating ANSI Class 150: 275 psig (19 bar) ANSI Class 300: 720 psig (49.6 bar) ANSI Class 600: 1440 psig (99 bar) Temperature Range -20°F to 450°F (-29°C to 232°C) (depending on seal materials) Seal Type Metal-to-Metal (primary seal)

Technical Parameters Parameter Specification Model Fisher i2P-100 Type Two-Wire, Intrinsically Safe, Current-to-Pressure (I/P) Transducer Input Signal 4-20 mA DC (Two-wire) Output Signal 3-15 psig (0.2-1.0 bar); other ranges available. Power Supply 24 V DC nominal (12 to 30 V DC loop power) Supply Air Pressure 20 to 60 psig (1.4 to 4.1 bar), clean and dry. Air Consumption (No Load) Typically 0.25 SCFM (0.42 m³/hr) Accuracy ±0.5% of span Intrinsic Safety Rating FM/CSA/CENELEC approved for Class I, Division 1, Groups A, B, C, D hazardous locations. Ambient Temperature Range -40°F to 180°F (-40°C to 82°C) Enclosure Rating NEMA 4X (IP66) when properly installed in an IS system. Mounting Panel mount, DIN rail, or direct to actuator.

Technical Parameters Parameter Specification Product Name Fisher WhisperFlo™ Aerodynamic Trim Type Multi-Stage, Noise Attenuation Trim Primary Fluid Service Gases and Steam (Compressible Fluids) Noise Reduction Capability Typically 15 to 25 dBA (depending on initial pressure drop and valve size) Pressure Drop Capability Capable of handling very high pressure drops (ΔP), often in excess of 1000 psi. Compatible Valve Bodies Fisher easy-e™, G-Series, 1050/1051, and other cage-style globe valves. Trim Construction Cylindrical cage with multiple stages of perforated plates or stacked disks. Wetted Materials Stainless Steel (Standard), Alloy Steel Size Range Designed to fit valve sizes from 1" to 12" (DN 25 to DN 300) and larger. Temperature Limits Limited by the valve body, typically up to 800°F (427°C) or more. Flow Capacity (Cv) Varies by size and specific trim design. Provides a balanced Cv for its noise reduction class.

Technical Parameters Parameter Specification Model Fisher™ 4660 Type Digital Valve Positioner with Foundation Fieldbus Communication Protocol Foundation Fieldbus H1 (31.25 kbit/s) Input Signal Digital setpoint via Fieldbus Supply Air Pressure 20 to 100 psig (1.4 to 6.9 bar) Air Consumption Less than 0.2 SCFM (0.33 m³/hr) at steady state. Stem Travel Range 0.2 to 4.0 inches (5.0 to 101.6 mm) for linear actuators; 25° to 120° for rotary actuators. Accuracy Better than ±0.5% of span (including linearity, hysteresis, and dead band). Ambient Temperature Range -40°F to 185°F (-40°C to 85°C) Enclosure Rating NEMA 4X (IP66/67) Hazardous Area Approvals FM, CSA, ATEX, IECEx for Class I, Division 1 / Zone 1 hazardous locations. Function Blocks Contains standard Fieldbus function blocks (AI, AO, PID, etc.) for distributed control. Partial Stroke Test (PST) Configurable for automated testing of Safety Instrumented Functions (SIF).
