Technical Parameters Parameter Specification Notes Model ZB32N-1,5 Equivalent to ZB32N-1.5 Product Type Level Junction Terminal Block Rated Voltage 400 V Rated Current 24 A Rated Cross-Section (Wire Size) 1.5 mm² This is the core specification indicated by "1,5". It can also accommodate a range of wire sizes, e.g., 0.5 mm² to 2.5 mm² (check datasheet). Number of Positions 1 (sold individually) Multiple units can be snapped together to form a block. Connection Technology Cage Clamp (Spring Loaded) Tool-less or with a screwdriver for opening. Conductor Type Solid, stranded, or finely stranded with ferrule Torque (for cage clamp) Typically 0.6 - 0.8 Nm Refer to datasheet for exact value. Mounting DIN Rail NS 35/7.5 or NS 32 Standard 35mm DIN rail. Material (Housing) Polycarbonate (PC), Transparent Material (Clamp) Steel, Tin-plated Material (Conductor) Copper, Tin-plated Approvals / Standards UL 1059, CSA, CE, RoHS Recognized Component

Technical Parameters Parameter Specification Notes Model ZB32N-6 Product Type Level Junction Terminal Block Rated Voltage 400 V Rated Current 76 A Rated Cross-Section (Wire Size) 6.0 mm² This is the core specification indicated by "-6". It can also accommodate a range of wire sizes, e.g., 1.5 mm² to 6.0 mm² (check datasheet). Number of Positions 1 (sold individually) Multiple units can be snapped together to form a block. Connection Technology Cage Clamp (Spring Loaded) Tool-less or with a screwdriver for opening. Conductor Type Solid, stranded, or finely stranded with ferrule Torque (for cage clamp) Typically 0.6 - 0.8 Nm Refer to datasheet for exact value. Mounting DIN Rail NS 35/7.5 or NS 32 Standard 35mm DIN rail. Material (Housing) Polycarbonate (PC), Transparent Material (Clamp) Steel, Tin-plated Material (Conductor) Copper, Tin-plated Approvals / Standards UL 1059, CSA, CE, RoHS Recognized Component

Technical Parameters Parameter Specification Notes Model XTOD005CC1 Type Solid State Relay (SSR) DC Input to DC Output Load Voltage 5 to 60 VDC Load Current 5 A max Absolute Max Load Current 7.5 A Non-repetitive peak On-State Resistance ≤ 50 mΩ On-State Voltage Drop ≤ 0.5 V @ 5A Input Control Voltage 3 to 10 VDC Input Current 10 mA typical @ 5V Turn-On Time 1 ms max Turn-Off Time 0.1 ms max Isolation Voltage 1500 Vrms Between input and output Operating Temperature -40°C to +80°C Storage Temperature -40°C to +100°C Mounting PCB Mount Through-hole type Package Plastic, sealed Weight Approx. 10 g Agency Approvals UL 508, CE, CQC Recognized / Certified

Technical Parameters Parameter Specification Notes Model ZB32N-5 Product Type Level Junction Terminal Block Rated Voltage 400 V Rated Current 76 A Rated Cross-Section (Wire Size) 5.0 mm² This is the core specification indicated by "-5". It can also accommodate a range of wire sizes, e.g., 1.5 mm² to 6.0 mm² (check datasheet). Number of Positions 1 (sold individually) Multiple units can be snapped together to form a block. Connection Technology Cage Clamp (Spring Loaded) Tool-less or with a screwdriver for opening. Conductor Type Solid, stranded, or finely stranded with ferrule Torque (for cage clamp) Typically 0.6 - 0.8 Nm Refer to datasheet for exact value. Mounting DIN Rail NS 35/7.5 or NS 32 Standard 35mm DIN rail. Material (Housing) Polycarbonate (PC), Transparent Material (Clamp) Steel, Tin-plated Material (Conductor) Copper, Tin-plated Approvals / Standards UL 1059, CSA, CE, RoHS Recognized Component

Technical Parameters Parameter Specification Notes Model DIL M32C-XHI11-S Product Type Contactor with Integrated Electronic Module Rated Operational Current (Ie) 32 A at AC-3, 400 V Rated Operational Power (Pme) 15 kW (20 hp) at AC-3, 400 V Rated Insulation Voltage (Ui) 690 V Rated Operational Voltage (Ue) 230 V / 400 V / 690 V AC Rated Control Supply Voltage (Us) 230 V AC Key specification for the "-S" variant Motor Load (Utilization Category AC-3) 32 A at 400 V 15 kW 25 A at 690 V 18.5 kW Resistive Load (Utilization Category AC-1) 32 A at 400 V Mechanical Durability 10 million operations Electrical Durability 1.5 million operations at AC-3, 32 A, 400 V Integrated XHI11 Module Functions • Forbidden Simultaneity (Electronic Interlock): Prevents two interlocked contactors from closing simultaneously. • Motor Locking Protection: Protects against jammed motors. • Phase Reversal Protection: Detects and protects against incorrect phase sequence. • Timer Functions: On-delay and Off-delay. • Status Indication: Via diagnostic LEDs. Terminals Cage Clamp For main and auxiliary circuits Mounting Standard DIN Rail (35mm) or Panel Mount Agency Approvals CE, cULus, RoHS, etc.

Technical Parameters Parameter Specification Notes Model DILM32C-XHI11-S Product Type Contactor with Electronic Blocking Module Rated Operational Current (Ie) 32 A at AC-3, 400 V Rated Operational Power (Pme) 15 kW / 20 hp at AC-3, 400 V Rated Insulation Voltage (Ui) 690 V Rated Operational Voltage (Ue) 230 V / 400 V / 690 V AC Rated Control Circuit Voltage 230 VAC This is a critical detail for this specific "-S" model. Motor Load (AC-3) 32 A at 400V 15 kW 25 A at 690V 18.5 kW Resistive Load (AC-1) 32 A at 400V Mechanical Durability 10 million operations Electrical Durability 1.5 million operations at AC-3, 32A, 400V Integrated XHI11 Module Functions • Electronic Interlock: Prevents simultaneous closing of two linked contactors. • Motor Locking Protection: Protects against jammed motors. • Phase Reversal Protection: Protects against incorrect phase sequence. • Timer Functions: On/Off delays. • Diagnostic LEDs: Status indication. Terminals Cage Clamp / Screw Clamp Mounting Standard DIN Rail (35mm) or Panel Mount Agency Approvals CE, cULus, RoHS, etc.

Technical Parameters Parameter Specification Notes Model XTCE007B10 Type Solid State Relay (SSR) DC Input to AC Output Load Voltage 48 to 660 VAC Load Current 10 A max Absolute Max Load Current 100 A Non-repetitive peak for 10 ms Input Control Voltage 3 to 32 VDC Input Current 15 mA typical Turn-On Time 1/2 cycle max + 2 ms Dependent on AC line frequency Turn-Off Time 1/2 cycle max + 2 ms Dependent on AC line frequency Isolation Voltage 4000 Vrms Between input and output dv/dt (Static) 100 V/µs min Operating Temperature -40°C to +80°C (With appropriate heatsink) Mounting Panel / Heat Sink Mount Standard SSR footprint Screw Terminals M4 For main terminals Weight Approx. 50 g Agency Approvals UL 508, cULus, CE, GL, RoHS Recognized / Certified

Technical Parameters Parameter Specification Notes Model XTCE025CC10 Type Solid State Relay (SSR) DC Input to DC Output Load Voltage 5 to 25 VDC Load Current 10 A max Absolute Max Load Current 15 A Non-repetitive peak On-State Resistance ≤ 30 mΩ On-State Voltage Drop ≤ 0.3 V @ 10A Input Control Voltage 3 to 10 VDC Input Current 10 mA typical @ 5V Turn-On Time 1 ms max Turn-Off Time 0.1 ms max Isolation Voltage 1500 Vrms Between input and output Operating Temperature -40°C to +80°C Storage Temperature -40°C to +100°C Mounting PCB Mount Through-hole type Package Plastic, sealed Weight Approx. 12 g Agency Approvals UL 508, CE, CQC Recognized / Certified

Key Parameters Category Description / Value Product Line Eaton DILAC Control Units Type Control and Monitoring Unit Compatibility Designed for use with Eaton motor protection devices Functions Control, monitoring, status indication Mounting Designed for integration with compatible Eaton devices Connection Electrical connections for control and signaling Standards IEC/EN 60947 series

Key Parameters Category Description / Value Product Line Eaton XT Timer Relays Type Multi-function Timer Relay Supply Voltage Typically 24-240V AC/DC Time Range Adjustable (seconds/minutes/hours) Output Type Relay contact output Mounting DIN rail (35mm) Connection Screw terminals Standards IEC/EN 60947-5-1
