Technical Parameters Parameter Specification Product Series Eaton P1 Product Type Miniature Circuit Breaker (MCB) Number of Poles 1 Pole (1P) Rated Current (In) 25 A Tripping Characteristic Type B (Instantaneous trip: 3 to 5 x In) Rated Voltage (Ue) 230/400 V AC Rated Breaking Capacity (Icn) 10 kA (10,000 A) at 400V AC Standards Compliance IEC/EN 60898-1 Electrical Life ≥ 10,000 cycles Mechanical Life ≥ 20,000 cycles Terminal Connection Suitable for rigid and flexible copper conductors Mounting DIN Rail Mounting (35 mm, EN 60715) Width (Modular Size) 18 mm (1 module)

Technical Parameters Parameter Specification Product Series Eaton NZM3 Product Type Programmable Electronic Trip Unit with Communication Rated Current (In) of Frame 1300 A (This is the fixed rating for this specific trip unit) Rated Operational Voltage (Ue) Up to 690 V AC Rated Insulation Voltage (Ui) 1000 V AC Rated Frequency 50/60 Hz Protection Functions L (Long-time Overload), S (Short-time), I (Instantaneous), G (Ground Fault) Communication Protocol Modbus RTU over RS-485 Setting Adjustment Programmable via front interface or communication network Display Typically includes an LCD for status and fault indication Mounting Integrated into a compatible NZM3 circuit breaker frame Standards Compliance IEC 60947-2

Technical Parameters Parameter Specification Product Series Eaton XTC Product Type AC Power Contactor Rated Operational Current (Ie) 32 A Rated Thermal Current (Ith) 32 A Poles 3 (Main Poles) Auxiliary Contacts 1 Normally Open (NO) Rated Operational Voltage (Ue) Up to 690 V AC Control Coil Voltage The "AO" suffix likely specifies a standard coil voltage (e.g., 230V AC). Must be confirmed from datasheet. Motor Load Rating (AC-3) 15 kW / 20 HP at 400V AC Electrical Life (AC-3) Typically 1 - 2 million operations Mechanical Life Typically 10 - 15 million operations Mounting DIN Rail (35mm) or Panel Mount Terminal Type Screw Clamp Standards Compliance IEC 60947-4-1, UL 508, CSA C22.2 No. 14

Technical Parameters Parameter Specification Product Series Eaton P1 Product Type Miniature Circuit Breaker (MCB) Number of Poles 1 Pole (1P) Rated Current (In) 32 A Tripping Characteristic Type B (Instantaneous trip: 3 to 5 x In) Rated Voltage (Ue) 230/400 V AC Rated Breaking Capacity (Icn) 10 kA (10,000 A) at 400V AC (Please verify from the specific catalog) Standards Compliance IEC/EN 60898-1 Electrical Life ≥ 10,000 cycles Mechanical Life ≥ 20,000 cycles Terminal Connection Suitable for rigid and flexible copper conductors Mounting DIN Rail Mounting (35 mm, EN 60715) Width (Modular Size) 18 mm (1 module)

Technical Parameters Parameter Specification Product Series Eaton DILM Product Type Contactor Rated Operational Current (Ie) 9 A (at AC-3, 400V) Rated Thermal Current (Ith) 25 A Motor Load Rating (AC-3) 4 kW / 5.5 HP at 400V AC Poles 3 (Main Poles) Rated Operational Voltage (Ue) Up to 690 V AC Control Coil Voltage 230 V AC, 50/60 Hz Mechanical Life 10 - 30 million operations Electrical Life (AC-3) 1 - 3 million operations Terminal Type Screw Clamp Mounting DIN Rail (35mm) or Panel Mount Standards Compliance IEC 60947-4-1, UL 508, CSA C22.2 No. 14

Technical Parameters Parameter Specification Product Series Eaton XTC Product Type DC Power Contactor Rated Operational Current (Ie) 40 A Rated Operational Voltage (Ue) Up to 1000 V DC Poles 1 Pole (Typically) Control Coil Voltage Various DC voltages available (e.g., 12V DC, 24V DC, 48V DC). The "D" in the model number may indicate a standard DC coil voltage, which must be confirmed from the datasheet. Rated Making/Breaking Capacity Specified for DC loads (e.g., L/R ≤ 30ms) Electrical Life Varies with load (e.g., 100,000 operations at rated current) Mechanical Life Typically millions of operations Mounting Screw mounting or DIN Rail Terminal Type Screw clamp for power and control connections Standards Compliance IEC 60947-4-1, UL 508

Technical Parameters Parameter Specification Product Series Eaton Modular UPS Power Module (for 93PM frames) Product Type Hot-swappable UPS Power Module Topology Double Conversion Online Nominal Output Power per Module 11 kVA / 11 kW Input Voltage: 200/208/220/230/240/380/400/415 V AC, 3-Phase + Neutral Frequency: 50/60 Hz (Auto-sensing) Output Voltage: 200/208/220/230/240/380/400/415 V AC (Configurable) Waveform: Pure Sine Wave Efficiency >96% in online mode (at full load) Battery Voltage Compatible with the external battery system of the UPS frame Form Factor Modular cartridge for specific Eaton UPS chassis Key Feature Hot-swappable for online maintenance and scalability Typical System Configuration Installed in a central UPS frame (e.g., 93PM) to build systems from 11kVA to 100s of kVA

Technical Parameters Parameter Specification Product Series Eaton Modular UPS Power Module (for 93PM / 9PX G2 frames) Product Type Hot-swappable UPS Power Module Topology Double Conversion Online Nominal Output Power per Module 6 kVA / 6 kW Input Voltage: 200/208/220/230/240 V AC, 3-Phase + Neutral Frequency: 50/60 Hz (Auto-sensing) Output Voltage: 200/208/220/230/240 V AC (Configurable) Waveform: Pure Sine Wave Efficiency >96% in online mode (at full load) Battery Voltage Compatible with the external battery system of the UPS frame Form Factor Modular cartridge for specific Eaton UPS chassis Key Feature Hot-swappable for online maintenance and scalability Typical System Configuration Installed in a central UPS frame to build systems from 6kVA to 100s of kVA

Technical Parameters Parameter Specification Product Series Eaton 9PX EBM (External Battery Module) Product Type External Battery Module / Pack Compatibility Designed for specific Eaton 9PX UPS models (e.g., 3kVA, 6kVA, 10kVA models). Must be verified with compatibility chart. Nominal Battery Voltage 240 V DC (This is a typical voltage for EBMs supporting higher-power UPS systems) Form Factor 3U Rackmount Mounting 19-inch server rack (3 Rack Units high) Battery Type Sealed, maintenance-free Lead-Acid batteries (VRLA) Battery Configuration Multiple internal battery trays or strings Communication Connects to the host UPS for monitoring battery status and health Typical Use Extending the runtime of 9PX UPS systems

Technical Parameters Parameter Specification Product Series Eaton DIL (DILER Series) Product Type Timer Relay / Time Delay Relay Timing Function On-Delay (G) Operating Voltage 24 V DC Time Range Adjustable (e.g., 0.1s - 30h, or another specific range for the -31 model) Number & Type of Output Contacts Typically 1 Changeover (CO) contact (SPDT - 1 NO + 1 NC) Rated Operational Current (Ie) Typically 6 - 8 A (for the output relay contacts) Mounting DIN Rail (35 mm) Setting Method Potentiometer or DIP-switches Status Indication LED Standards Compliance IEC 60947-5-1, UL 508, CSA C22.2 No. 14
