Parameter Specification Product Type Wirewound Power Resistor Model Number HLW70K Description Aluminum Housed Wirewound Resistor, 70 Ohm Resistance Value (R) 70 Ohms (Ω) Resistance Tolerance Typically ±5% or ±10% Rated Power Typically in the range of 100W to 300W for this style, dependent on cooling. Construction Wirewound, aluminum housed with cooling fins Terminals Screw terminals Mounting Metal mounting brackets Application Load Resistor, Braking Resistor, Heating Element, Bleeder Resistor

Parameter Specification Product Series Eaton E2 (K Frame) Model Number E2K3400MNWA02D11S29 Description Electronic Motor Management Relay, 400A, w/ Comm & Display Motor Current Setting Range (FLA) Up to 400 A Poles 3 (for 3-phase motor protection) Rated Operational Voltage (Ue) 690V AC Rated Supply Voltage (Us) 24-240V AC/DC Display Advanced User Interface with Display Communication Integrated DeviceNet ("DN" in code) Protection Functions Thermal Overload (with Memory) Short-Circuit (Instantaneous) Phase Loss / Unbalance Jam / Stall Underload / Undercurrent Earth Fault (Restricted/Sensitive) Number of Starts / Time Between Starts RTD Inputs (for direct motor winding temperature monitoring) Control Functions Direct Start/Stop, Auto-restart, Fault Diagnostics Auxiliary Contacts Multiple programmable relays Mounting Panel-mounted or DIN Rail (with adapter) Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton E50 (General Purpose Relay) Model Number E50AR120 Description Plug-in General Purpose Relay, 3PDT, 10A, 120V AC Coil Contact Configuration 3PDT (3 Form C / 3 Changeover) Rated Load Current 10 A @ 277V AC Coil Voltage 120V AC Electrical Life Typically 100,000+ operations (at rated load) Mechanical Life Typically 10 million operations Mounting Plug-in base (e.g., 8 or 11-pin) Terminals Plug-in (screw terminals on the base) Standards & Certifications UL 508, CSA C22.2 No. 14, CE

Parameter Specification Product Series Eaton HMCP (Motor Circuit Protector) Model Number HMCPJ250W5L Description Motor Circuit Protector (MCP), 250A Frame, 5-Pole, 480V AC Frame Size 250A Poles 5 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 600V AC Short-Circuit Breaking Capacity Specific high value (e.g., 100kA, 150kA) depending on the "J" rating. Trip Unit Magnetic Instantaneous Only (No Thermal Overload) Instantaneous Pickup Setting Adjustable (typically a multiple of the frame size, e.g., 5x to 13x) Mounting Fixed Standards & Certifications UL 489, CSA C22.2 No. 5, IEC 60947-2

Parameter Specification Product Series Eaton E2 (Electronic Overload Relay) Model Number E2FM150TM Description Electronic Overload Relay, 130-150A, Self-Protected Motor Current Setting Range (FLA) 130 - 150 A Poles 3 (for 3-phase motor protection) Rated Operational Voltage (Ue) 690V AC Rated Supply Voltage (Us) 24V AC/DC - 240V AC/DC (for the control circuit) Protection Functions Overload (Class 5, 10, 15, 20, 25, 30 adjustable) Phase Loss Phase Unbalance Jam / Stall Protection Undercurrent Earth Fault Protection (Optional, may require external CT) Self-Protected Feature Yes (Integral HBC fuse for short-circuit protection of the control unit) Auxiliary Contacts 2 NO + 2 NC (95-96 / 97-98 / 99-100 / 101-102) Terminals Screw Terminals Mounting Mounts directly onto compatible contactors (e.g., Eaton DILM series) Communication Optional communication modules (e.g., PROFIBUS, Modbus, DeviceNet) available Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus

Parameter Specification Product Series Eaton HM (General Purpose Relay) Model Number HM4R12 Description Plug-in General Purpose Relay, 4PDT, 12A, 24V DC Coil Contact Configuration 4PDT (4 Form C / 4 Changeover) Rated Load Current 12 A @ 250V AC Coil Voltage 24V DC Electrical Life Typically 1 x 10^6 operations (at rated load) Mechanical Life Typically 10 x 10^6 operations Mounting Plug-in base (e.g., PA16-11B or similar) Terminals Plug-in (screw terminals on the base) Standards & Certifications IEC 61810-1, UL 508, CSA C22.2 No. 14

Parameter Specification Product Type Digital Panel Voltmeter Model Number DMV-630N/3 Description Digital Voltmeter, 3-Phase, 0-630V AC Measured System 3-Phase (with Neutral) Rated Voltage (Un) 400V / 480V AC Measuring Range 0 - 630V AC Power Supply Auxiliary supply (e.g., 80-270V AC/DC or 24V AC/DC) Display Digital Display (LED or LCD) Accuracy Typically ±0.5% to ±1% of reading Mounting Panel Mount (requires panel cutout) Connection Screw Terminals Standards & Certifications IEC 61010-1, UL 61010-1, CE

Parameter Specification Product Type Digital Panel Voltmeter Model Number DMV-1000N/3 Description Digital Voltmeter, 3-Phase, 0-1000V AC Measured System 3-Phase (with or without Neutral) Rated Voltage (Un) 690V AC Measuring Range 0 - 1000V AC Power Supply Typically 80-270V AC/DC or 24V AC/DC (Auxiliary supply) Display LED or LCD Digital Display Accuracy Typically ±0.5% of reading Mounting Panel Mount (Cut-out required) Connection Screw Terminals Standards & Certifications IEC 61010-1, UL 61010-1, CE

Parameter Specification Product Series Eaton ZM (Timer & Monitoring Relays) Model Number ZM-32-8-PKZ24 Description Multi-Function Timer Relay, 8-Pin, 24V AC/DC Supply Voltage (Us) 24V AC/DC Number of Outputs 1 Changeover (SPDT) Output Contact Rating Typically 8A @ 250V AC Timing Functions Multiple (e.g., On-delay, Off-delay, Interval, One-shot, Flasher) Time Range Adjustable, typically from 0.05s up to 300h (depends on selected function) Setting Method Via DIP-switches and a potentiometer or rotary switch Mounting DIN Rail (35mm) on an 8-pin socket Terminals Screw Clamp Status Indication LED for power and output status Standards & Certifications IEC/EN 61812-1, UL 508, CSA

Parameter Specification Product Series Eaton L630E Model Number 69D4630G03 (Full Assembly) / L630E (Relay Core) Description Thermal Overload Relay, 22-32A Motor Current Setting Range (FLA) 22 - 32 A Poles 3 (for 3-phase motor protection) Tripping Class 10 (Standard) Ambient Compensated Yes Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Mounting Mounts directly onto compatible contactors (e.g., Eaton DILM series) Standards & Certifications IEC/EN 60947-4-1, UL 508, CE, cULus
