Key Specifications
✔ Power Rating: 20 kW (25 HP)
✔ Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz
✔ Output Current: 43 A
✔ Overload Capacity:

150% for 60 seconds

110% continuous
✔ Control Method: Direct Torque Control (DTC)
✔ Braking Capacity (P901):

Continuous: 20 kW

Peak (60s): 30 kW
✔ Switching Frequency: 1-12 kHz (adjustable)
✔ Efficiency: >98%

Main Features
1. Advanced Motor Control
DTC technology for precise speed (±0.1%) and torque (±2%) control

Automatic motor adaptation for optimal performance

Flying start and torque boost functions

2. Brake Chopper (P901)
Handles regenerative energy during deceleration

Requires external brake resistor (sold separately)

LED status indicator for fault monitoring

3. Application Flexibility
Pre-programmed macros for:

Pumps & fans

Conveyors

Cranes/hoists

Built-in PID controller

Customizable application programming

4. Protection & Safety
Motor thermal protection (PTC/KTY support)

Short-circuit and ground fault protection

DC bus overvoltage/undervoltage protection

Safe Torque Off (STO) compliant

5. Connectivity
Standard:

RS485 (Modbus RTU)

Analog I/O (2xAI, 1xAO)

Digital I/O (3xDI, 1xDO)

Optional fieldbus:

PROFIBUS DP

DeviceNet

CANopen

Physical Specifications
Dimensions: 245 × 482 × 227 mm (W×H×D)

Weight: 14 kg

Enclosure Rating: IP21

Cooling: Forced air (filtered)

Ambient Temperature: 0-40°C (32-104°F)

The Schneider Electric Masterpact MVS 10N 3F5A5 is a high-performance low-voltage air circuit breaker (ACB) designed for fixed mounting in electrical distribution systems. As part of the Masterpact MVS range, it provides reliable circuit protection for industrial and commercial applications.
