Technical Specifications:

Power Rating: 0.75 kW (1 HP)

Input Voltage:

3-phase: 200-240V AC (-15%/+10%)

1-phase: 200-240V AC (-15%/+10%)

Output Current: 3.6 A

Overload Capacity: 150% for 60 seconds

Brake Chopper: Integrated (P901 option)

Switching Frequency: 1-12 kHz (adjustable)

Key Features:
✔ Advanced Control Modes:

DTC (Direct Torque Control) technology

Scalar control (V/f) mode

Customizable torque curves

✔ Application-Specific Features:

Pump and fan control macros

PID controller with sleep/wake function

Flying start capability

✔ Protection Functions:

Motor thermal protection

Short circuit protection

Ground fault detection

Overvoltage/undervoltage protection

Standard Interfaces:

Control Terminals:

2 analog inputs (0-10V/4-20mA)

3 digital inputs

1 relay output

1 analog output

Communication Options:

Modbus RTU (standard)

Optional fieldbus adapters (Profibus, DeviceNet)

Physical Characteristics:

Enclosure: IP21 (open chassis)

Cooling: Convection cooling

Ambient Temperature: 0-40°C (32-104°F) without derating

Mounting: Wall or DIN rail mounting
