The Emerson KJ4001X1-CA1 I/O Terminal Block is designed for industrial automation applications. It serves as a reliable interface for input signals in DeltaV systems, providing a robust solution for connecting sensors and other field devices.

Technical Data Parameter Specification Product Type Shunt Release (MX - Opening Coil) Compatible Series NZM1 Molded Case Circuit Breakers Rated Control Supply Voltage (Us) 208 - 250 V AC/DC Power Consumption Approx. 70 VA / 45 W (at 230V AC/DC) Typical value, confirm with datasheet Function Electrically trips the circuit breaker when the control voltage is applied. Duty Cycle Intermittent (Short-time). The coil must not be continuously energized. Mounting Factory-installed or field-mounted on the side of compatible NZM1 breakers. Connection Screw terminals for control wiring. Standards IEC 60947-1, IEC 60947-2

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, FAZ Series (Bussmann) Model Number FAZ-C2/3-RT Fuse Class & Rating Class CC Rated Current: 2 A Rated Voltage: 600V AC Number of Poles / Quantity 3 pieces (Typically supplied as a 3-pole set for a 3-phase application) Type Fast-Acting (Non-Time-Delay) Rated Voltage 600V AC / 300V DC Rated Breaking Capacity (Interrupting Rating) 200 kA AC (200,000 Amps) at 600V AC Approvals / Standards UL 248-4 (Class CC), CSA C22.2 No. 248.4 Electrical Characteristics Current-Limiting: Yes, extremely effective due to the low current rating. Melting I²t (2A): Exceptionally low, providing the highest level of component protection. Physical Dimensions Body: 13/32" x 1-1/2" (10.3mm diameter x 38.1mm length) Mounting / Fuse Holder Requires a compatible Class CC fuse holder or fuse block (e.g., Eaton FHCC100, KRP-C-100SP) Indicator / Feature RT - Rectangular Target (Visual Blown Indicator). An indicator pops out to provide a clear visual signal that the fuse has blown.
