Key Specifications
Power Rating: 200 kW (268 HP)

Input Voltage: 3-phase 380-480V AC (-15%/+10%), 50/60Hz

Output Current: 360 A

Overload Capacity: 110% continuous, 150% for 60s

Control Technology: Direct Torque Control (DTC)

Efficiency: >98.5% at full load

Braking Chopper: Integrated (requires external resistor)

System Components
ACS880-01-206A-3 Drive Unit:

Multi-layer PCB design for enhanced reliability

Heavy-duty IGBT power stage

Built-in EMC filter (Class A)

IP21 enclosure (IP54 kit available)

D150 Control Panel:

7" full-color touchscreen display

Multilingual interface (24 languages)

Real-time trending and data logging

USB port for parameter backup

Advanced Features
✔ Precision Control

Speed control accuracy: ±0.01% of setpoint

Torque control accuracy: ±1% of rated torque

Adaptive programming capability

✔ Application-Specific Functions

Multiple application macros

Customizable logic functions

Built-in safety functions (STO, SS1, SLS)

Advanced PID controller with feedforward

✔ Connectivity

Standard interfaces:

Ethernet (TCP/IP)

Modbus TCP

RS485 (Modbus RTU)

Optional fieldbus:

PROFIBUS DP-V1

PROFINET IRT

EtherNet/IP

CANopen

Physical Specifications
Drive Dimensions: 800 × 2200 × 450 mm (W×H×D)

Control Panel Dimensions: 210 × 170 × 60 mm

Total Weight: 185 kg

Cooling: Liquid cooling system

Ambient Temperature: 0-40°C (32-104°F) without derating
