Technical Parameters Parameter Value Notes Maximum Operating Pressure 350 bar 5,075 psi Rated Flow Capacity 19 L/min 5 US gpm Port Size NG06 CETOP 03 Standard Spool Configuration 3-position, 4-way Spring-centered, tandem center Solenoid Type Wet Pin DC Continuous Duty Voltage 24V DC Code 60 Power Consumption 26W At 20°C (68°F) Protection Rating IP65 Solenoid Standard Internal Leakage < 100 mL/min At rated pressure Response Time < 30 ms Solenoid actuation Electrical Specifications Parameter Specification Operating Voltage 24V DC ±10% Current Draw 1.1A typical Insulation Class Class F (155°C) Duty Cycle 100% continuous Connection Type ISO 4400 (DIN 43650 Form A) Coil Resistance 22 Ω ±10% Hydraulic Performance Parameter Specification Port P, A, B Pressure 350 bar maximum Port T Pressure 210 bar maximum Pressure Drop < 5 bar at rated flow Fluid Compatibility Petroleum-based hydraulic fluids Operating Temperature -20°C to +70°C Recommended Viscosity 10-100 mm²/s

The Bently Nevada 3300 XL 8 mm Proximity Probes are precision-engineered sensors designed for high-precision position detection in industrial automation systems. They are ideal for applications requiring reliable, non-contact measurement in harsh environments.

Engineered for industrial automation, the Honeywell 51308112-020 is designed to enhance efficiency and precision in critical applications across various industries.
