Key Parameters
Core Drive
Power: 45kW (60HP)

Input: 3-phase 525-690V AC (±10%)

Output: 60A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

Modules
N671 Encoder Interface

Supports incremental encoders

Resolution: Up to 4096 ppr

Protocols: RS422/TTL

P901 Brake Chopper

Braking power: 45kW cont.

Peak: 67.5kW (60s)
Requires external resistor

Performance
Speed accuracy: ±0.01% (with encoder)

Torque accuracy: ±1%

Switching freq.: 1-12kHz

Physical
Dimensions: 482×800×350mm (H×W×D)

Weight: 45kg

Cooling: Forced air

IP Rating: IP21

Certifications
CE, UL, cUL

SIL3/PL e

Key Parameters
Core Specifications
Power: 18.5kW (25HP)

Input: 3-phase 380-480V AC (±10%)

Output Current: 38A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

Brake System (P901)
Continuous Braking: 18.5kW

Peak Braking (60s): 27.75kW

External resistor required

Performance
Speed accuracy: ±0.1%

Torque accuracy: ±1%

Switching frequency: 1-12kHz adjustable

Physical
Dimensions: 245×482×227mm (W×H×D)

Weight: 14kg

Cooling: Forced air

Enclosure: IP21

Certifications
CE, UL, cUL

SIL3/PL e compliant

Key Parameters
Drive Unit
Power: 30kW (40HP)

Input: 3-phase 380-500V AC (±10%)

Output: 60A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

P901 Brake Chopper
Braking Power: 30kW continuous

Peak Capacity: 45kW (60s)

Requires external resistor

Performance
Speed accuracy: ±0.1%

Torque accuracy: ±1%

Switching freq.: 1-12kHz

Physical
Dimensions: 482×245×227mm (H×W×D)

Weight: 15kg

Cooling: Forced air

IP Rating: IP21

Certifications
CE, UL, cUL

SIL3/PL e compliant

Key Specifications
Parameter Value
Power Rating 18.5 kW (25 HP)
Input Voltage 3-phase 380-500V AC (±10%)
Output Current 38 A
Overload Capacity 150% for 60s
Control Method DTC (Direct Torque Control)
Efficiency >98%
Switching Frequency 1-12 kHz (adjustable)
Main Features
✔ Advanced Motor Control

Speed accuracy: ±0.1% (sensorless)

Torque accuracy: ±2% of rated

Flying start function

✔ Compact Design

Space-saving IP21 enclosure

Forced air cooling

Wall-mount installation

✔ Application Flexibility

10 pre-programmed macros

Built-in PID controller

Customizable logic

✔ Protection

Motor thermal protection

Short-circuit protection

Ground fault detection

✔ Connectivity

RS485 (Modbus RTU) standard

Optional fieldbus adapters

Physical Specs
Dimensions: 350 × 482 × 227 mm

Weight: 18 kg

Ambient Temp: 0-40°C

Certifications
CE

UL

cULus

IEC 61800-3

Key Specifications
Parameter Value
Power Rating 250 kW (335 HP)
Input Voltage 3-phase 380-500V AC (±10%)
Output Current 450 A
Overload Capacity 150% for 60s
Control Method DTC (Direct Torque Control)
Efficiency >98.5%
Switching Frequency 1-4 kHz (adjustable)
Main Features
✔ Precision Control

Speed accuracy: ±0.01% (with encoder)

Torque accuracy: ±1% of rated

Adaptive motor tuning

✔ Robust Construction

Heavy-duty IGCT power stage

IP21 enclosure (IP54 kit available)

50°C ambient operation

✔ Connectivity

Standard:

Ethernet (TCP/IP)

Modbus TCP

Optional:

PROFIBUS DP-V1

PROFINET IRT

✔ Safety

Safe Torque Off (STO)

Safe Stop 1 (SS1)

SIL3/PL e certified

Physical Specs
Dimensions: 900×2200×600 mm

Weight: 320 kg

Cooling: Liquid cooling system

Certifications
CE

UL 61800-5-1

cULus

DNV GL

Key Parameters
Core Drive
Power: 110kW (150HP)

Input: 3-phase 380-500V AC (±10%)

Output Current: 210A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

Modules
D150 Control Panel

7" color touchscreen

USB parameter backup

Real-time trending

P901 Brake Chopper

Braking power: 110kW cont.

Peak: 165kW (60s)
Requires external resistor

Performance
Speed accuracy: ±0.1%

Torque accuracy: ±1%

Switching freq.: 1-4kHz

Physical
Dimensions: 800×2200×450mm (W×H×D)

Weight: 220kg

Cooling: Liquid cooling (standard)

IP Rating: IP21

Certifications
CE, UL, cUL

SIL3/PL e

Key Specifications
Power Rating: 11 kW (15 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz

Output Current: 25 A

Overload Capacity: 150% for 60 seconds

Control Technology: DTC (Direct Torque Control)

Brake Chopper: Integrated (P901 module)

Switching Frequency: 1-12 kHz (adjustable)

Efficiency: >98%

Main Features
✔ Advanced Motor Control

Sensorless speed control (±0.1% accuracy)

Automatic motor adaptation

Torque control mode (±2% accuracy)

Flying start function

✔ Braking System (P901)

Handles regenerative energy

Requires external brake resistor

LED status indicator

150% braking torque capacity

✔ Application Flexibility

Multiple application macros

Built-in PID controller

Pump and fan control curves

Customizable application programming

✔ Protection Features

Motor thermal protection

Short circuit protection

Ground fault detection

DC bus overvoltage protection

Physical Characteristics
Dimensions: 245 × 482 × 227 mm (W×H×D)

Weight: 12 kg

Enclosure Rating: IP21

Cooling Method: Forced air

Ambient Temperature: 0-40°C (32-104°F)

Key Specifications
Power & Performance
Rated Power: 4 kW (5 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 9.5 A

Overload Capacity:

110% continuous

150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Braking Capacity (P901):

Continuous: 4 kW

Peak (60s): 6 kW

Switching Frequency: 1-12 kHz (adjustable)

Efficiency: >98%

Main Features
✔ Advanced Motor Control

DTC technology (±0.1% speed accuracy)

Automatic motor adaptation

Flying start capability

✔ Brake Chopper (P901)

Handles regenerative energy

Requires external brake resistor

LED status indicator

✔ Compact Design

Space-saving IP21 enclosure

Convection cooling (fanless)

Easy wall-mount installation

Key Parameters
Drive Unit
Power: 90kW (125HP)

Input: 3-phase 380-480V AC (±10%)

Output: 180A

Control: DTC (Direct Torque Control)

Overload: 150% for 60s

Modules
D150 Control Panel

7" color touchscreen

USB parameter backup

Real-time trending

P901 Brake Chopper

Braking power: 90kW cont.

Peak: 135kW (60s)
Requires external resistor

Performance
Speed accuracy: ±0.1%

Torque accuracy: ±1%

Switching freq.: 1-12kHz

Physical
Dimensions: 800×2200×450mm

Weight: 185kg

Cooling: Forced air

IP Rating: IP21

Certifications
CE, UL, cUL

SIL3/PL e

Key Specifications
Power & Performance
Rated Power: 18.5 kW (25 HP)

Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz

Output Current: 38 A

Overload Capacity: 110% continuous

Control Method: Direct Torque Control (DTC)

Efficiency: >98% (IE4 equivalent)

Water Industry Features
✔ Pump-Specific Intelligence

Multi-pump controller (up to 4 pumps)

Dry-run protection with automatic restart

Anti-clogging cycle for wastewater

Leak detection algorithm

✔ Advanced Connectivity

Built-in Modbus RTU & PROFIBUS

IoT-ready with optional cellular module

SCADA integration templates

✔ Robust Protection

Corrosion-resistant (IP66/NEMA 4X)

Enhanced EMC filtering

50°C ambient operation capability

Physical Specifications
Dimensions: 350 × 482 × 227 mm (H×W×D)

Weight: 18 kg

Cooling: Convection (fanless)

Material: Stainless steel screws & coated PCB

Certifications
UL 61800-5-1

CE

cULus

IEC 61800-3 Cat C3

NEMA 4X/12 (optional)
