GE PWA 5085606 – Industrial printed wiring assembly (PWA) designed for GE automation systems. Features high-reliability circuitry, rugged construction, and compatibility with GE control platforms.

Key Features:

8mm high-temperature probe with Inconel 718 housing

Wide measuring range (0.5-3.0mm) with 8mV/µm sensitivity

Exceptional temperature resistance (-50°C to +250°C continuous, +300°C short-term)

IP68 submersible rating and 200 bar pressure capability

MIL-spec connector for secure signal transmission

Technical Specifications:

Frequency response: 0-15kHz (±3dB)

Power supply: -18 to -24VDC

Output signal: -2 to -22VDC

Double-sealed construction (graphite/Viton®)

M10×1 threaded mounting

Performance Highlights:

±1% linearity across full range

Active temperature compensation (±0.03%/°C)

100g vibration resistance

Mineral-insulated stainless steel cable included

Typical Applications:

Gas turbine hot gas path monitoring

Nuclear power plant primary coolant pumps

Geothermal energy systems

Aerospace component testing

High-pressure compressor trains

Certifications & Compliance:

Meets API 670 and ISO 7919 requirements

ATEX/IECEx versions available

CE and SIL 2 compliant

Installation Notes:

Requires AISI 4140/4340 steel targets

NIST-traceable calibration provided

Special mounting procedures for >250°C applications

This system is specifically designed for critical monitoring in power generation, oil & gas, and aerospace applications where conventional sensors would fail. Its robust construction ensures long-term reliability in extreme temperature and pressure conditions.
