Core Specifications
Drive Unit (ACS800-01-0003-3):

Output Power: 2.2kW (3HP) at 400V

Output Current: 5.5A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: >96% at full load

Switching Frequency: 1-16kHz (adjustable)

P901 Control Panel:

7" high-resolution color touchscreen

Multi-language interface (12 languages)

Integrated web server functionality

8GB data logging capacity

USB 3.0 configuration port

Real-time clock with battery backup

Key System Features
Advanced Control:
✔ Precision Regulation: ±0.2% speed accuracy
✔ Application Macros: 6 pre-programmed configurations
✔ Process Control: Single PID controller with auto-tuning
✔ Energy Optimization: Power consumption monitoring

Connectivity:

Standard Interfaces:

Modbus RTU (RS485)

Ethernet

Optional Modules:

PROFIBUS DP

PROFINET IRT

DeviceNet

Safety Systems:

Safe Torque Off (STO) - SIL3 certified

Motor thermal protection

Short-circuit protection

Phase loss detection

Mechanical Specifications
Enclosure Rating: IP21 (NEMA 1)

Dimensions: 200 × 400 × 180mm (W×H×D)

Weight: 8.5kg (complete system)

Cooling: Natural convection

Noise Level: <55dB at 1m

Core Specifications
Drive Unit (ACS800-01-0016-3):

Output Power: 11kW (15HP) at 400V

Output Current: 24A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: >97% at full load

Switching Frequency: 1-12kHz (adjustable)

P901 Control Panel:

7" high-brightness color touchscreen

Multi-language interface (12 languages)

Built-in web server for remote monitoring

8GB data logging capacity

USB port for configuration backup

Real-time clock with battery backup

Key System Features
Advanced Control:
✔ Precision Regulation: ±0.1% speed accuracy
✔ Application Macros: 8 pre-programmed configurations
✔ Process Control: Built-in PID with auto-tuning
✔ Energy Optimization: Adaptive motor control algorithm

Connectivity:

Standard Interfaces:

PROFIBUS DP

Modbus RTU (RS485)

Ethernet

Optional Modules:

PROFINET IRT

EtherNet/IP

BACnet MS/TP

Safety & Protection:

Integrated Safety:

Safe Torque Off (STO) - SIL3 certified

Safe Stop 1 (SS1)

Protection Features:

Motor thermal protection

Ground fault monitoring

DC bus overvoltage protection

Mechanical Specifications
Enclosure Rating: IP21 (NEMA 1)

Cooling System: Temperature-controlled fan

Dimensions: 250 × 500 × 220mm (W×H×D)

Weight: 18kg (complete system)

Noise Level: <58dB at 1m

Core Specifications
1. ACS800-01-0040-3 Drive Unit

Output Power: 30kW (400V)

Output Current: 60A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 97.5% at full load

2. D150 Braking Module

Braking Capacity: 150% of drive rating

Peak Power: 45kW (10% duty cycle)

Response Time: <2ms

3. P901 Control Panel

7" high-resolution color touchscreen

Multi-language interface (16 languages)

Integrated web server functionality

16GB data logging capacity

USB 3.0 configuration port

Key System Features
Performance Enhancements:
✔ Precision Control: ±0.05% speed accuracy
✔ Rapid Deceleration: 200% braking torque capacity
✔ Process Optimization: Dual PID controllers with auto-tuning
✔ Energy Recovery: Regenerative braking capability

Connectivity & Integration:

Standard Interfaces:

PROFIBUS DP

Modbus RTU

Ethernet

Optional Modules:

PROFINET IRT

EtherNet/IP

OPC UA

Safety Systems:

Safe Torque Off (STO) - SIL3 certified

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Automatic self-diagnostics

Physical Specifications
Enclosure Rating: IP21 (NEMA 1)

Dimensions: 350 × 700 × 250mm (W×H×D)

Weight: 28kg (complete system)

Cooling: Smart temperature-controlled fans

Noise Level: <60dB at 1m

Key Specifications
Parameter Specification
Output Current 32A
Rated Power 15kW (400V, 4-pole motor)
Input Voltage 3-phase 380-480V AC (±10%)
Overload 150% for 60 seconds
Control Method Direct Torque Control (DTC)
Efficiency >98% at full load
Enclosure IP21 (open chassis)
Advanced Features
Precision Control:
✔ Ultra-fast torque response (<5ms)
✔ Speed accuracy: ±0.01% of set value
✔ Adaptive motor tuning (AMT)
✔ Automatic energy optimization

Connectivity:

Standard interfaces:

Dual Ethernet ports (1Gbps)

PROFINET IRT

Modbus RTU (RS485)

Optional modules:

PROFIBUS DP-V2

EtherNet/IP

BACnet MS/TP

Safety & Protection:

Integrated safety functions (STO, SS1, SLS)

SIL3/PL e certified

Advanced diagnostics with predictive maintenance

Motor thermal protection

Mechanical Specifications
Dimensions: 250 × 600 × 220mm (W×H×D)

Weight: 15kg

Cooling: Smart fan control

Ambient Temperature: 0°C to +50°C

Relative Humidity: 5-95% non-condensing

Core Specifications
Drive Unit (ACS800-01-0060-3):

Output Power: 45kW (60HP) at 400V

Output Current: 90A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity:

150% for 60 seconds

200% for 3 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 97.5% at full load

Switching Frequency: 1-8kHz (adjustable)

P901 Control Panel:

7" high-brightness color touchscreen

Multi-language interface (14 languages)

Integrated web server with remote monitoring

16GB data storage capacity

USB 3.0 configuration port

Real-time clock with battery backup

Key System Features
Advanced Performance:
✔ Precision Control: ±0.05% speed accuracy
✔ Adaptive Programming: 12 application macros
✔ Process Optimization: Dual PID controllers
✔ Energy Management: Power consumption monitoring

Connectivity:

Standard Interfaces:

PROFINET IRT

Modbus RTU (RS485)

Ethernet/IP

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

OPC UA

Safety Systems:

SIL3 certified safety functions:

Safe Torque Off (STO)

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Automatic self-diagnostics

Mechanical Specifications
Enclosure: IP21 (NEMA 1)

Cooling System: Smart temperature-controlled fans

Dimensions: 350 × 750 × 300mm (W×H×D)

Weight: 32kg (complete system)

Noise Level: <63dB at 1m

Core Specifications
Drive Unit (ACS800-01-0016-5):

Output Power: 11kW (15HP) at 200V

Output Current: 39A continuous

Input Voltage: 3-phase 200-240V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: >97% at full load

Switching Frequency: 1-12kHz (adjustable)

P901 Control Panel:

7" color touchscreen display

Multi-language interface (12 languages)

Built-in web server for remote monitoring

8GB data logging capacity

USB port for configuration backup

Key System Features
Advanced Control:
✔ Precision Regulation: ±0.1% speed accuracy
✔ Application Macros: 8 pre-programmed configurations
✔ Process Control: Built-in PID with auto-tuning
✔ Energy Optimization: Adaptive motor control

Connectivity:

Standard interfaces:

PROFIBUS DP

Modbus RTU

Ethernet

Optional fieldbus modules available

Safety & Protection:

Safe Torque Off (STO) - SIL3 certified

Motor thermal protection

Ground fault monitoring

DC bus overvoltage protection

Mechanical Specifications
Enclosure: IP21 (NEMA 1)

Cooling: Forced air with temperature control

Dimensions: 250 × 500 × 220mm (W×H×D)

Weight: 18kg (complete system)

Core Specifications
1. ACS800-01-0120-3 Drive Unit

Output Power: 90kW (400V)

Output Current: 180A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: 97.8% at full load

2. D150 Braking Module

Braking Capacity: 150% of drive rating

Peak Power: 135kW (10% duty cycle)

Response Time: <2ms

3. P901 Control Panel

7" high-resolution color touchscreen

Multi-language interface (16 languages)

Integrated web server functionality

16GB data logging capacity

USB 3.0 configuration port

Key System Features
Performance Enhancements:
✔ Precision Control: ±0.05% speed accuracy
✔ Rapid Deceleration: 200% braking torque capacity
✔ Process Optimization: Dual PID controllers with auto-tuning
✔ Energy Recovery: Regenerative braking capability

Connectivity & Integration:

Standard Interfaces:

PROFIBUS DP

Modbus RTU

Ethernet

Optional Modules:

PROFINET IRT

EtherNet/IP

OPC UA

Safety Systems:

Safe Torque Off (STO) - SIL3 certified

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Automatic self-diagnostics

Physical Specifications
Enclosure Rating: IP21 (NEMA 1)

Dimensions: 450 × 900 × 350mm (W×H×D)

Weight: 55kg (complete system)

Cooling: Smart temperature-controlled fans

Noise Level: <65dB at 1m

Key Specifications
Parameter Specification
Output Current 61A
Rated Power 30kW (400V, 4-pole motor)
Input Voltage 3-phase 380-480V AC (±10%)
Overload 150% for 60 seconds
Control Method Direct Torque Control (DTC)
Efficiency >98% at full load
Enclosure IP21 (open chassis)
Advanced Features
Precision Control:
✔ Ultra-fast torque response (<5ms)
✔ Speed accuracy: ±0.01% of set value
✔ Adaptive motor tuning (AMT)
✔ Automatic energy optimization

Connectivity:

Standard interfaces:

Dual Ethernet ports (1Gbps)

PROFINET IRT

Modbus RTU (RS485)

Optional modules:

PROFIBUS DP-V2

EtherNet/IP

BACnet MS/TP

Safety & Protection:

Integrated safety functions (STO, SS1, SLS)

SIL3/PL e certified

Advanced diagnostics with predictive maintenance

Motor thermal protection

Mechanical Specifications
Dimensions: 300 × 700 × 250mm (W×H×D)

Weight: 22kg

Cooling: Smart fan control

Ambient Temperature: 0°C to +50°C

Relative Humidity: 5-95% non-condensing

Core Components
1. ACS800-104-0030-3 Drive Unit

Output Power: 30kW (400V)

Output Current: 60A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Efficiency: >97% at full load

2. N664 Control Panel

LCD display with backlight

Multilingual interface (8 languages)

USB port for parameter transfer

Status LEDs for quick diagnostics

IP54 protection rating (front panel)

Key Features
Performance:
✔ Precise Speed Control: ±0.1% speed regulation
✔ Adaptive Programming: 5 application macros
✔ Energy Optimization: Automatic motor adaptation
✔ Fast Response: <5ms torque response time

Connectivity:

Built-in Modbus RTU (RS485)

Optional fieldbus modules:

PROFIBUS DP

DeviceNet

CANopen

Protection:

Motor thermal protection

Short-circuit protection

Phase loss detection

Ground fault monitoring

Mechanical Specifications
Enclosure: IP21 (main unit), IP54 (panel)

Dimensions: 300 × 500 × 250mm (W×H×D)

Weight: 18kg (complete system)

Cooling: Temperature-controlled fan

Ambient Temperature: 0°C to +40°C

Core Specifications
Drive Module (ACS800-04-0610-7):

Output Power: 610kW (400V configuration)

Output Current: 1180A continuous

Input Voltage: 3-phase 380-500V AC (±10%)

Overload Capacity:

110% continuous

150% for 60 seconds

Control Method: Direct Torque Control (DTC)

Efficiency: 98.5% at full load

Switching Frequency: 1-3kHz (adjustable)

P901 Control Panel:

10" high-brightness industrial touchscreen

Multi-language interface (20 languages)

Integrated web server with secure remote access

64GB data logging capacity

Dual USB 3.1 configuration ports

Real-time predictive maintenance functions

Key System Features
Advanced Performance:
✔ Ultra-Precise Control: ±0.01% speed accuracy
✔ Adaptive Control: 20 application-specific macros
✔ Process Optimization: Quad PID controllers with AI tuning
✔ Harmonic Mitigation: <3% THD with active front end

Connectivity & Integration:

Standard Interfaces:

4× 1Gbps Ethernet ports (PROFINET IRT, EtherNet/IP)

OPC UA over TCP/IP

IEC 61850 protocol support

Optional Modules:

PROFIBUS DP-V2

BACnet MS/TP

Wireless LAN module

Safety Systems:

SIL3/PL e certified safety functions:

Safe Torque Off (STO)

Safe Stop 1 (SS1)

Safe Speed Monitor (SSM)

Safe Brake Control (SBC)

Redundant safety processors

Continuous self-monitoring

Mechanical Specifications
Enclosure: IP21 (cabinet-mounted)

Cooling System: Liquid-assisted forced air cooling

Dimensions: 800 × 2200 × 600mm (W×H×D)

Weight: 450kg (complete system)

Noise Level: <70dB at 1m

Cooling Airflow: 3000m³/hr
