IC65N 2P C25A

The Schneider Electric iC65N 2P C25A is a two-pole (2P) miniature circuit breaker (MCB) designed for overload protection and short-circuit protection in single-phase or split-phase circuits. The C25A model provides 25A rated current and is equipped with a C characteristic curve, making it suitable for applications with moderate inrush currents, such as for lighting circuits, small motors, and heating systems.

open
TEL：+86 13600179521
Mail：info@hongkongeasy.com
info@hongkongeasy.com
WhatsApp
Parameters
Request a Quote
Return to List
Specifications General Product Type: Miniature Circuit Breaker (MCB) Model: iC65N 2P C25A Configuration: 2P (two-pole) Rated Current: 25A Mounting: DIN rail Application: Overload and short-circuit protection for single-phase or split-phase circuits Electrical Ratings Rated Operational Voltage (Ue): Typically 230V AC Rated Insulation Voltage (Ui): 400V AC Rated Impulse Withstand Voltage (Uimp): 4kV Short-Circuit Withstand Capacity: 10kA Rated Frequency: 50/60Hz Operating Temperature Range: Typically -5°C to +40°C Performance & Protection Features Thermal-Magnetic Protection: Provides overload protection via thermal mechanism and short-circuit protection via magnetic mechanism C Curve: Ideal for circuits where moderate inrush currents are expected, such as motors, lighting, and heating circuits Instantaneous Short-Circuit Protection: Quick disconnection in the event of a short circuit Clear Trip Indicator: Visual indication when the breaker trips due to overload or short-circuit events Mechanical & Environmental Degree of Protection: Typically IP20 (front face) Housing: Compact design for easy panel integration Cable Connections: Screw terminals for secure connection Mechanical Durability: ~10,000 operating cycles Mounting: DIN rail mounting for easy integration into control panels or distribution boards Accessories & Options Auxiliary Contacts: Available for status monitoring and remote signaling Shunt Release: Option for remote tripping Undervoltage Release: Available for additional protection against undervoltage conditions
