Power Rating:16kW

Operating Voltage:DC 24V to 120V

Operating Current:Up to 250A

Protection Class:IP20

Operating Temperature Range:-20°C to +60°C

Weight:Approximately 3kg

    The ABB TD180N16KOF Diode Power Modules are engineered with advanced semiconductor technology, providing reliable power handling capabilities essential for industrial automation systems. These modules are optimized for use in demanding environments where they must withstand harsh conditions without compromising performance.

    Equipped with a robust design, these diodes offer superior protection against transient voltage surges, ensuring uninterrupted operation of connected equipment. They are particularly suitable for applications requiring high surge current handling, such as motor drives, variable frequency drives (VFDs), and power electronics.

    Featuring M8 connectors, the modules provide a secure and efficient connection solution, facilitating quick installation and maintenance. The compact dimensions of 172 x 50 x 140mm make them ideal for space-constrained applications, allowing for easy integration into existing control cabinets.

    The ABB TD180N16KOF modules operate within a wide temperature range of -25°C to +70°C, making them suitable for various industrial settings from cold storage facilities to hot manufacturing plants. Their IP20 protection rating ensures dust resistance, safeguarding the modules from external contaminants.

    In addition to their technical specifications, these diode power modules are designed with user-friendliness in mind, offering intuitive labeling and clear documentation for easy troubleshooting and system maintenance. ABB’s commitment to quality and reliability is reflected in the long lifespan and minimal maintenance requirements of these components, ensuring a low total cost of ownership for industrial operations.
