The Rockwell MPL-A430H-MJ72AAMP-Series 240V AC Rotary Servo Motor is designed for high-performance applications requiring precise motion control. With its robust construction and advanced technology, it is ideal for industrial automation, robotics, and manufacturing processes.
open
close
Rated Voltage:240V AC
Power Rating:2.2 kW
Speed Range:0 – 3000 RPM
Torque:4.5 Nm
Encoder Resolution:2000 counts per revolution
Interface:EtherNet/IP
Weight:18 kg
Dimensions:165 mm x 140 mm x 190 mm (LxWxH)
The Reliance Electric H4030PJ00AB Servo Motor is engineered with advanced features including IP65 rated enclosure protection against dust and water ingress. It features winding thermostats for enhanced thermal management, ensuring optimal performance under various operating conditions.
Equipped with a brushless sinusoidal commutation system, this servo motor delivers smooth operation and high efficiency, making it ideal for demanding industrial applications. Its integral optical encoder provides accurate position feedback with a resolution of 2500 PPR, facilitating precise control and positioning.
The motor comes with MS connectors for both power and encoder connections, ensuring reliable and secure electrical connections. Optional shaft seals are available for additional environmental protection, particularly in harsh industrial settings.
For applications requiring dynamic braking, an integrally mounted brake is offered with selectable coil voltages of 90VDC or 24VDC, providing immediate stopping power when needed. This feature enhances safety and control in applications involving rapid deceleration.
With a wide operating temperature range of 0…+55°C, the H4030PJ00AB Servo Motor is suitable for use in diverse environments. Its standard servo motor flange design ensures compatibility with existing systems, simplifying integration and installation.
