The ABB DSQC363 Axis Board is an advanced industrial control module designed for precise motion control applications, ensuring high performance and reliability in manufacturing and automation sectors.
home
The ABB DSQC363 Axis Board is an advanced industrial control module designed for precise motion control applications, ensuring high performance and reliability in manufacturing and automation sectors.
open
close
Operating Voltage:DC 24V
Communication Interface:EtherCAT
Input Channels:16 Digital Inputs
Output Channels:16 Digital Outputs
Power Consumption:Max 3W
Operating Temperature:-20°C to +70°C
Dimensions:140mm x 100mm x 27mm
Weight:Approx. 100g
Experience unparalleled precision in your industrial automation processes with the ABB DSQC363 Axis Board. Designed to meet the demands of complex machinery setups, this Axis Board ensures smooth integration, offering unparalleled control over your equipment’s movements.
Featuring a compact yet robust design, the DSQC363 Axis Board boasts dimensions of 102x100x35 mm, weighing just 150 grams, making it suitable for panel mounting without adding unnecessary bulk.
With its wide operating voltage range of DC 24V, the DSQC363 can handle various power supplies effortlessly, ensuring compatibility across different industrial environments. Its current rating of 5A supports efficient power distribution.
Equipped with two analog input channels and two digital input channels, this Axis Board allows for versatile signal handling. It seamlessly connects via RS232 and RS485 interfaces, facilitating reliable communication within your automation system.
Operate in extreme conditions with confidence, as the DSQC363 Axis Board is designed to function between -20°C and +70°C. This robust temperature range ensures consistent performance in various climates, enhancing reliability in diverse industrial settings.
