Manufacturing Company:General Electric

Model Number:DS3800HPTK

Application Category:Mark IV DS3800

Functionality:Gate driver for the Mark IV Speedtronic series, providing precise control over turbine operations

Component Count:Fifteen long grey resistors rated at 18 Ohms ±5%, ten color-coded resistors indicating their capacity, thirteen diodes of various colors, three capacitors of varying sizes, a large glass fuse, and a small red LED

Physical Design:Comprises a thin metal divider with eight contact points, labeled from A through H and then J with triangular symbols between each letter, and equipped with two screw points and two plastic clips for easy installation

Manufacturing Information:Labeled with circuit board number, manufacturer’s logo (GE), and manufacturing location

    The GE-FANUC DS3800HPTK GATE DRIVER CARD is an essential component in turbine control systems, offering unparalleled reliability and efficiency. Its robust design ensures seamless integration with various control architectures, providing precise gate control and improved system performance.

    Featuring solid-state relay outputs, this card significantly reduces maintenance requirements and enhances system longevity compared to traditional mechanical relays. The high-resolution 24-bit input allows for fine-tuning of control signals, resulting in superior control accuracy.

    With its wide operating temperature range (-20°C to +60°C), this board is suitable for a variety of industrial environments, from cold storage facilities to hot manufacturing plants. Its DC 24V operation ensures compatibility with a broad spectrum of power sources commonly found in industrial settings.

    Equipped with a versatile RS-485 communication interface, the DS3800HPTK facilitates easy setup and integration with other control devices, streamlining system configuration and management. The board’s ability to handle up to 32 channels makes it ideal for complex turbine control scenarios where multiple actuators or valves need to be controlled.

    Engineered for durability and reliability, the GE-FANUC DS3800HPTK GATE DRIVER CARD is backed by comprehensive support services and a commitment to continuous innovation. It is part of the GE-FANUC line of products known for their precision, quality, and adaptability in demanding industrial environments.
