Emerson 5X00106G01

Emerson 5X00106G01 Product Description

Overview

Emerson 5X00106G01 is a feeder protection and control device used in medium voltage distribution systems. It adopts digital technology and can provide various protection and control functions to meet the various needs of medium voltage distribution systems. 5X00106G01 can provide the following functions:

Feedline protection: overcurrent protection, short circuit protection, overvoltage protection, undervoltage protection, frequency protection, power protection, etc

Transformer protection: overload protection, excitation surge protection, differential protection, zero sequence harmonic protection, etc

Motor protection: overload protection, short circuit protection, single-phase protection, phase failure protection, overvoltage protection, undervoltage protection, etc

Control functions: switch control, circuit breaker control, isolator control, load control, etc

Measurement functions: voltage, current, power, power factor, etc

Relay protection and control devices

5X00106G01

Product parameters

Rated voltage: 12 kV

Rated current: 630 A

Circuit breaker capacity: 2500 A

Communication interface: RS-232、RS-485、Ethernet

Working temperature range:- 40° C to+70° C

Size: 600mm x 400mm x 200mm

Weight: 50kg

Product application

5X00106G01 is suitable for various medium voltage distribution systems, including:

Industrial and Civil Buildings

Power plants and substations

Oil and gas

Chemical industry

Metallurgy

Other applications that require medium voltage distribution systems

Product Features

Powerful function: 5X00106G01 can provide multiple protection and control functions to meet the various needs of medium voltage distribution systems

High reliability: 5X00106G01 adopts digital technology and has undergone rigorous testing to ensure its reliability

Easy to use: 5X00106G01 provides user-friendly software and programming tools, making it easy for users to use
