This GE SR750-P5-G1-S1-HI-A20-R industrial control system is designed for precise monitoring and control in various industrial applications, featuring high reliability and robust performance.
home
This GE SR750-P5-G1-S1-HI-A20-R industrial control system is designed for precise monitoring and control in various industrial applications, featuring high reliability and robust performance.
WhatsApp
Baud Rate:300 to 19200 baud
Frequency Range:25 to 60 Hz nominal
Current Inputs:5 A phase current inputs, 1 A zero sequence current inputs, and sensitive ground current inputs
Relay Dimensions:Approximately 18cm W, 16.5cm L, 21.5cm H
Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states, and 8 output relays
Pollution Degree:II
Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01
Insulation Voltage:300 V
Certified Product:Yes
The GE SR750-P5-G1-S1-HI-A20-R is a robust feeder management relay designed for efficient distribution systems. This relay combines advanced protection features with precise control capabilities, making it ideal for industrial applications. Its communication protocols support Modbus RTU or DNP 3.0, enabling seamless integration with existing systems. With 4 current channels, 3 voltage channels, 14 logic input states, and 8 output relays, this device offers comprehensive monitoring and control functions. Its compact design allows for easy installation on standard 19-inch panels, making it a versatile solution for various setups. The relay’s protective features include overcurrent protection, under/overfrequency protection, and ground fault protection, ensuring reliable operation in demanding environments. Furthermore, it supports waveform capture for detailed analysis and trending data using the EnerVista 750 software program. This makes the GE SR750-P5-G1-S1-HI-A20-R an essential component for modern industrial control systems.
