The Schneider STBDAI7220 is a standard analog input module designed for distributed I/O solutions in industrial automation systems. It enables precise measurement of analog signals and integrates seamlessly with the Modicon STB system.
home
The Schneider STBDAI7220 is a standard analog input module designed for distributed I/O solutions in industrial automation systems. It enables precise measurement of analog signals and integrates seamlessly with the Modicon STB system.
open
close
Brand:Schneider
Model:STBDAI7220
Module Type:Digital Input Module
Input Channels:16
Voltage Range:0-30V DC
Operating Temperature:-25°C to +70°C
Power Supply:12-24V DC
Communication Protocol:Modbus RTU
Protection Class:IP20
Weight:0.5kg
Dimensions:120mm x 100mm x 60mm
The Schneider STBDAI7220 is an essential component for any industrial automation system. Designed for reliability and precision, this module offers eight channels of high-resolution analog inputs, capable of handling a wide range of input signals from -10V to +10V or 0 to 20mA. With a resolution of up to 16 bits, it ensures accurate and consistent data acquisition, which is crucial for effective process control. The module supports multiple communication interfaces including Modbus RTU/ASCII, Profibus DP, and CANopen, allowing seamless integration into existing systems. The robust design and wide operating temperature range (-25°C to +70°C) make it suitable for harsh industrial environments, ensuring reliable performance even under challenging conditions. The Schneider STBDAI7220 is built with high-quality materials and undergoes rigorous testing to guarantee long-term durability and performance. Whether you are upgrading your current system or starting a new project, this module provides the flexibility and accuracy needed for modern industrial automation needs.
