The GE SR745-W2-P1-G1-HI-E-H is an advanced industrial transformer protection system designed to monitor and safeguard transformers, autotransformers, and reactors. It offers a large 40-character display for easy viewing and expanded keypad for efficient manual entry of setpoints.
WhatsApp
Model Number:SR745-W2-P1-G1-HI-E-H
Order Number:DS215TCEAG1BZZ01A
Transformer Protection System:Yes
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
Display Type:40-character Enhanced LCD
Dimensions:9″H x 7 ⅛”D x 7″W
RTD Type:3-wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
The GE SR745-W2-P1-G1-HI-E-H is designed for efficient management and protection of transformers, autotransformers, and reactors. Featuring an enhanced 40-character LCD display, it provides a more intuitive interface for operators, allowing them to easily monitor and adjust settings. The expanded keypad simplifies manual entry of setpoints, ensuring quick and accurate adjustments. With a compact design measuring 9 inches in height, 7 inches in width, and 7 ⅛ inches in depth, this system can be conveniently mounted on a standard 19-inch panel. Its robust construction ensures reliable performance in demanding industrial environments. The front of the unit is equipped with LEDs that provide real-time alerts for various statuses and errors, helping to minimize downtime and maintenance issues. The SR745-W2-P1-G1-HI-E-H is ideal for industries requiring precise control and monitoring solutions.
