ABB 5SDF0860H0003

ABB 5SDF0860H0003 Product Overview
Product Overview

ABB 5SDF0860H0003 is a high-voltage diode module mainly used in power electronic equipment. This module has the characteristics of high voltage resistance, high current, and fast response speed, and is widely used in fields such as frequency converters, electric traction, and industrial automation.

Product Features

High voltage resistance: capable of withstanding high voltage environments and suitable for high-voltage power systems.

High current: can carry high current and meet the needs of high-power applications.

Fast recovery: With fast recovery characteristics, suitable for high-frequency switch circuits.

High reliability: Advanced packaging technology and reliable materials are used to ensure long-term stable operation.

Miniaturization: Modular design, compact size, easy to install.

ABB 5SDF0860H0003

Product parameters (typical values, please refer to the product manual for specific parameters)

Model: 5SDF0860H0003

Brand: ABB

Type: High voltage diode module

Voltage withstand value: 6kV

Average rectified current: depending on the specific model

Packaging form: PRESS-FIT

Working temperature: -40 ℃~+150 ℃

Product specifications

Compliant with international standards such as IEC and ANSI

Certification: CE, UL and other certifications

Series Introduction

This product belongs to ABB's series of high-voltage diode module products, with multiple models and specifications to meet the needs of different customers.

Function and Application

Rectification: Convert alternating current into direct current.

Continuation: Provide a continuation path in a circuit.

Clamp: Limit voltage spikes.

application area

Power electronic equipment: frequency converter, inverter, charging station

Industrial automation: motor drive, welding equipment

Rail transit: electric locomotives, subway

New energy: photovoltaic power generation, wind power generation
