CC-pcnt01: Isolated Pulse Counter Module

Key features in 4 words:
Isolated → Electrical noise immunity

Pulse Counter → Core function (digital pulse accumulation)

Module → Industrial embeddable format

Ultra-compact versions (for labels/BOMs):
Isolated Pulse Counter (CC-pcnt01)

Pulse Counter Mod. w/Isolation

CW4500: 4500-Count Digital Counter Module

Key features in 6 words:
4500-Count: Max counting capacity

Digital: Discrete pulse input (e.g., PLC/encoder signals)

Counter: Core function

Module: Industrial embeddable hardware

Ultra-compact alternatives (for labels/schematics):
4500-Ct Digital Counter (CW4500)

Digital Counter Mod. 4500

Why this works:
"4500-Count" immediately conveys critical capacity (avoids misreading as frequency/voltage)

"Digital" specifies input type (essential for compatibility)

"Module" maintains consistency with previous codes (CD-820, RM7840G1022)

Omits redundant specs (e.g., voltage/speed) unless specified in datasheets

CD-820: ±820mA DC Current Detection Module

Key features conveyed:
Core Function: Current Detection

Critical Spec: ±820mA bidirectional range

Signal Type: DC (direct current)

Form Factor: Module (implying integration capability)

Ultra-compact alternatives:
±820mA DC Current Sensor (CD-820)

DC Curr. Det. Mod. ±820mA

Why this works:
± symbol clarifies bidirectional measurement

"Detection" emphasizes sensing/conversion (vs. control/protection)

"Module" denotes industrial embeddable hardware

DC specification prevents ambiguity with AC sensors

RM7840G1022: 10A/22VDC SPST-NO Relay Module

Key details included:
Electrical Rating: 10A current capacity at 22V DC

Contact Type: SPST-NO (Single-Pole Single-Throw, Normally Open)

Function: Relay Module (electromechanical switching device)

Alternative shorter formats:
10A/22VDC SPST Relay (RM7840G1022)

SPST-NO Relay, 10A @ 22VDC (RM7840G1022)

SC-UMIX01: Universal Signal Mixer/Converter Module (RTU Interface)

Honeywell CC-PAIL51
Function: 8-Channel Analog Input Module for Experion® C-Series I/O, with HART protocol support.

Key Features:

Inputs: 8 isolated 4–20mA channels (±0.1% accuracy, 16-bit resolution).

HART Integration: Pass-through digital communication for smart field devices.

Safety Isolation: 1500 VAC (channel-to-channel and channel-to-system).

Speed: 10 ms per channel scan.

Compatibility:

Mounts in C200/C300 I/O chassis (e.g., CIOM racks).

Robust Design:

Industrial-grade (-40°C to +70°C; ATEX/IECEx Zone 2, SIL 2/3 certified).

Honeywell CC-IP0101
Function: Profibus DP Interface Module for Honeywell Experion® C-Series controllers (C200/C300).

Key Role:

Connects Experion controllers to Profibus DP field devices (sensors, drives, I/O slaves).

Supports high-speed communication (up to 12 Mbps) with redundant ports for daisy-chaining.

Critical Features:

1500 VAC isolation (field-to-system safety).

Industrial hardened: Operates in -40°C to +70°C harsh environments.

DIP-switch addressing (1–126).

Compliance:

CE, ATEX Zone 2, SIL 2 (optional).

Honeywell CC-PSP401
Function: 120W Power Supply Module for Experion® C-Series I/O systems.

Key Features:

Input: 85–265 VAC (50/60 Hz) or 88–300 VDC (universal).

Output: 24 VDC, 5A (120W max).

Redundancy: Supports N+1 backup (hot-swappable).

Protections: Short-circuit, over-voltage, and thermal shutdown.

Compatibility:

Designed for Experion C200/C300 I/O chassis (e.g., CIOM/HIOM racks).

Robust Design:

Industrial-grade (-40°C to +70°C; 5–95% humidity).

Certifications: UL, CE, ATEX Zone 2.

Honeywell CC-PCNT02
Function: Profibus DP Termination Module for Honeywell Experion® PKS systems.

Key Role:

Passive termination device ensuring signal integrity at both ends of Profibus DP networks (per IEC 61158-2).

Integral 220Ω resistor prevents signal reflection/data errors.

Compatibility:

Works with Experion C200/C300 controllers and Profibus DP I/O modules (e.g., CIOM series).

Installation:

DIN-rail mounted; requires no external power.

Environmental:

Industrial temp range (-40°C to +70°C).
